LumiOpal Omni D40 360°

group name: 360Flex™ Neon flex

Min Order: 1 piece

brand name: SunStone Custom Hardware Manufacturer

Nearest port for product export: TIANJIN, SHANGHAI, QINGDAO, LIANYUNGANG

Delivery clauses under the trade mode: FOB, CFR, CIF, EXW

Acceptable payment methods: T/T, L/C, D/P D/A

update time: Thu, 21 Nov 2024 17:12:27 GMT

contact supplier

Paramtents

Model NO. TLI015-51
Emitting Color Yellow, Cold White, White, RGB, Warm White
Wire 2wire, 3wire, 4wire
IP Rating IP20
Certification CCC, CE, C-tick, ETL, RoHS, SAA
LED Chips Brand CREE/Luminus/Citizen
Input Voltage 220-240V / 100-120V / 100-277V AC, 50-60Hz
Angle 25°X75°
Product Weight 0.6kg
Working Time (Hours) 50000

Packging & Delivery

Min Order1 piece

Briefing

With high density LED chips mounted on FPC, the phosphor can be the CCT regulator and also the diffuser to create dot free lighting effect, it is high CRI and high efficacy, perfect for shallow profiles in under cabinet lighting applications.

Detailed

Model No.	OS40D-SW-144	OS40D-RGB-144	OS40D-RGBW-144
Power	14.4W/m	14.4W/m	14.4W/m		14.4W/m
CCT/Color	2200K~5700K	2200K+5700K	RGB		RGBW=2200K~5700K
Lumen output	2200K 684 Lm/m CRI 90+ 2700K 820 Lm/m CRI 90+ 3000K 875 Lm/m CRI 90+ 4000K 957 Lm/m CRI 90+ 5700K 957 Lm/m CRI 90+	2200K 308 Lm/m 5700K 423 Lm/m 2000K + 684 Lm/m 5700K	RGB 397 Lm/m Red 82 Lm/m Green 292 Lm/m Blue 37 Lm/m		Total432 Lm/m CRI 80+ 307 Lm/m RGB 124 Lm/m CRI 80+ 112 Lm/m CRI 90+ 102 Lm/m CRI 95+
MAXRUN	5m	5m	5m		5m
LEDs/m	280LEDs/m	448LEDs/m	240LEDs/m		240LEDs/m
Cut Length	50mm	62.5mm		50mm	50mm
CRI(White)	CRI90+~95+	CRI90+~95+	/		White CRI 90+~95+
Voltage	24V DC
Dimmable	Yes (PWM, DALI, 0/1-10V, Triac)
IP Rating	IP65
Ambient temp.	-35°C ~ 45°C
Beam Angle	360°
Bend ratio	R>220mm
Strip length/reel	0.5m ~ 50m
Lifespan	50,000Hrs

Package
LED Bar/ Street/Bedroom/Kitchen/Ceiling Strip Light

LED Bar/ Street/Bedroom/Kitchen/Ceiling Strip Light
